WAGO 714 Series Straight Through Hole Header, 15 Contact(s), 3.5 mm Pitch, 1 Row, Shrouded
- RS 제품 번호:
- 223-623
- 제조사 부품 번호:
- 714-145
- 제조업체:
- WAGO
Subtotal (1 Box of 100 units)*
₩843,612.40
일시적 품절
- 2026년 2월 16일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
Box(es) | Per Box | 한팩당* |
|---|---|---|
| 1 + | ₩843,612.40 | ₩8,435.56 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 223-623
- 제조사 부품 번호:
- 714-145
- 제조업체:
- WAGO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | WAGO | |
| Product Type | Header | |
| Series | 714 | |
| Current | 8A | |
| Pitch | 3.5mm | |
| Housing Material | Polyphthalamide | |
| Number of Contacts | 15 | |
| Number of Rows | 1 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | MCS | |
| Mount Type | Through Hole | |
| Contact Plating | Tin | |
| Contact Material | Electrolytic Copper | |
| Row Pitch | 3.5mm | |
| Termination Type | Through-Hole Reflow (THR) Soldering | |
| Minimum Operating Temperature | 60°C | |
| Maximum Operating Temperature | 100°C | |
| Tail Pin Length | 3.4mm | |
| Contact Gender | Male | |
| Standards/Approvals | EN61984, UL 1059 | |
| Voltage | 160 V | |
| 모두 선택 | ||
|---|---|---|
브랜드 WAGO | ||
Product Type Header | ||
Series 714 | ||
Current 8A | ||
Pitch 3.5mm | ||
Housing Material Polyphthalamide | ||
Number of Contacts 15 | ||
Number of Rows 1 | ||
Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Connector System MCS | ||
Mount Type Through Hole | ||
Contact Plating Tin | ||
Contact Material Electrolytic Copper | ||
Row Pitch 3.5mm | ||
Termination Type Through-Hole Reflow (THR) Soldering | ||
Minimum Operating Temperature 60°C | ||
Maximum Operating Temperature 100°C | ||
Tail Pin Length 3.4mm | ||
Contact Gender Male | ||
Standards/Approvals EN61984, UL 1059 | ||
Voltage 160 V | ||
- COO (Country of Origin):
- DE
The Wago THT Male Header connector is engineered for versatile PCB applications, featuring straight solder pins designed for ease of installation. With a robust housing composed of THR compatible insulation material, it is optimised for lead free reflow soldering, ensuring reliability and compliance with modern standards. The innovative design accommodates both horizontal and vertical mounting, further enhancing its adaptability. Its precise pin spacing allows for compact configurations, making it an excellent choice for complex electronic assemblies.
Offers variable coding to enhance connection security
Lightweight construction aids in reducing overall assembly weight
Robust housing material ensures durability in demanding environments
Solder pins arranged in line for straightforward integration onto PCBs
Compliant with multi connection system standards for reliability
