WAGO 721 Series Straight Through Hole Header, 8 Contact(s), 5 mm Pitch, 1 Row, Shrouded
- RS 제품 번호:
- 222-353
- 제조사 부품 번호:
- 721-138/001-000
- 제조업체:
- WAGO
Subtotal (1 Box of 100 units)*
₩423,325.50
일시적 품절
- 2026년 7월 15일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
Box(es) | Per Box | 한팩당* |
|---|---|---|
| 1 + | ₩423,325.50 | ₩4,233.45 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 222-353
- 제조사 부품 번호:
- 721-138/001-000
- 제조업체:
- WAGO
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | WAGO | |
| Series | 721 | |
| Product Type | Header | |
| Current | 12A | |
| Pitch | 5mm | |
| Housing Material | Polyamide 66 | |
| Number of Contacts | 8 | |
| Number of Rows | 1 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | MCS | |
| Mount Type | Through Hole | |
| Contact Plating | Tin | |
| Contact Material | Electrolytic Copper | |
| Row Pitch | 5mm | |
| Termination Type | Solder | |
| Minimum Operating Temperature | 60°C | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 100°C | |
| Tail Pin Length | 5mm | |
| Standards/Approvals | RoHS | |
| Voltage | 32V | |
| 모두 선택 | ||
|---|---|---|
브랜드 WAGO | ||
Series 721 | ||
Product Type Header | ||
Current 12A | ||
Pitch 5mm | ||
Housing Material Polyamide 66 | ||
Number of Contacts 8 | ||
Number of Rows 1 | ||
Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Connector System MCS | ||
Mount Type Through Hole | ||
Contact Plating Tin | ||
Contact Material Electrolytic Copper | ||
Row Pitch 5mm | ||
Termination Type Solder | ||
Minimum Operating Temperature 60°C | ||
Contact Gender Male | ||
Maximum Operating Temperature 100°C | ||
Tail Pin Length 5mm | ||
Standards/Approvals RoHS | ||
Voltage 32V | ||
- COO (Country of Origin):
- PL
The Wago THT Male Header offers a reliable connection solution designed for versatility in PCB mounting, featuring a space efficient design. Its robust construction ensures 100% protection against mismating, making installations straightforward and error free. With a pin cross section of 1 x 1 mm, this connector is well suited for high density applications, while its effective horizontal or vertical mounting options cater to a variety of assembly preferences.
Light grey colour offers a clean and professional appearance
Includes anti rotation protection to ensure stable connections
Lightweight build facilitates simple handling during installation
Suitable for use in environments with limited temperature range
Offers options for gold plated contact surfaces for enhanced conductivity
Backed by numerous international safety approvals for peace of mind
