- RS 제품 번호:
- 186-9259
- 제조사 부품 번호:
- 74VHC123AM
- 제조업체:
- onsemi
2375 <재고있음> 5-9영업일내 홍콩 발송
추가완료!
단가 개당가격(25개가 1팩안에)
₩1,524.812
수량 | 한팩당 | 한팩당* |
25 - 100 | ₩1,524.812 | ₩38,111.666 |
125 + | ₩1,505.838 | ₩37,654.567 |
*다른 단위에 대한 가격 표시 |
- RS 제품 번호:
- 186-9259
- 제조사 부품 번호:
- 74VHC123AM
- 제조업체:
- onsemi
참조 문서
제정법과 컴플라이언스
제품 세부 사항
74VHC Family, Fairchild Semiconductors
Advanced High-Speed CMOS Logic
Operating Voltage 2.0 to 5.5
Compatibility: Input CMOS, Output CMOS
Operating Voltage 2.0 to 5.5
Compatibility: Input CMOS, Output CMOS
High Speed: tPD = 8.1 ns (typ) at TA = 25°C
Low Power Dissipation:ICC = 4 μA (Max) at TA = 25°C
Active State: ICC = 600 μA (Max) at TA = 25°C
High Noise Immunity: VNIH = VNIL = 28% VCC (min)
Power down protection is provided on all inputs
Pin and function compatible with 74HC123A
Applications
This product is general usage and suitable for many different applications
Low Power Dissipation:ICC = 4 μA (Max) at TA = 25°C
Active State: ICC = 600 μA (Max) at TA = 25°C
High Noise Immunity: VNIH = VNIL = 28% VCC (min)
Power down protection is provided on all inputs
Pin and function compatible with 74HC123A
Applications
This product is general usage and suitable for many different applications
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
74VHC Family
사양
속성 | 값 |
---|---|
Logic Family | VHC |
Logic Function | Monostable Multivibrator |
Number of Elements per Chip | 8 |
Maximum High Level Output Current | -8mA |
Maximum Low Level Output Current | 8mA |
Minimum Pulse Width | 5 ns |
Maximum Propagation Delay Time @ Maximum CL | 29.5 ns @ 50 pF |
Maximum Quiescent Current | 40µA |
Mounting Type | Surface Mount |
Package Type | SOIC |
Pin Count | 16 |
Dimensions | 10 x 4 x 1.5mm |
Height | 1.5mm |
Length | 10mm |
Maximum Operating Supply Voltage | 5.5 V |
Width | 4mm |
Propagation Delay Test Condition | 50pF |
Maximum Operating Temperature | +85 °C |
Minimum Operating Temperature | -40 °C |
Minimum Operating Supply Voltage | 2 V |
