Name: Microchip dsPIC Microprocessor dsPIC33CH128MP508 16 bit MCU, DSP 200 MHz 28-Pin SSOP
Brand: Microchip
SKU: 175-7180
Price: 6220.92 KRW
Availability: LimitedAvailability

수량

수량 선택 또는 입력

제품 정보를 선택해 유사 제품을 찾기

모두 선택	제품 정보	값
	브랜드	Microchip
	Product Type	Microprocessor
	Series	dsPIC33CH128MP508
	Device Core	dsPIC
	Data Bus Width	16bit
	Instruction Set Architecture	MCU, DSP
	Maximum Clock Frequency	200MHz
	Mount Type	Surface
	Minimum Supply Voltage	3V
	Package Type	SSOP
	Pin Count	28
	Maximum Supply Voltage	3.6V
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	85°C
	Standards/Approvals	RoHS
	Height	2mm
	Length	10.5mm
	Width	8.2 mm
	Number of Cores	2
	Automotive Standard	No

	모두 선택
	브랜드 Microchip
	Product Type Microprocessor
	Series dsPIC33CH128MP508
	Device Core dsPIC
	Data Bus Width 16bit
	Instruction Set Architecture MCU, DSP
	Maximum Clock Frequency 200MHz
	Mount Type Surface
	Minimum Supply Voltage 3V
	Package Type SSOP
	Pin Count 28
	Maximum Supply Voltage 3.6V
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 85°C
	Standards/Approvals RoHS
	Height 2mm
	Length 10.5mm
	Width 8.2 mm
	Number of Cores 2
	Automotive Standard No

Microchip Technology DSP Microcontroller

The Microchip Technology DsPIC33CH family type SSOP package, surface mount, 28-pin and 16-bit CMOS based DSP microcontroller has a voltage rating that ranges between 3V and 3.6V. It has a master core with 64KB to 128KB of program flash with ECC and 16k RAM. Slave core with 24KB of program RAM (PRAM) with ECC and 4k data memory RAM.

Features and Benefits

• 40-bit wide accumulators

• Code efficient (C and Assembly) CPU architecture designed

• Communication interface 3 UART, 3 4-Wire SPI/I2S and CAN bus

• Dual Partition for Slave PRAM Live Update

• Fast 6 cycle divide

• Five sets of interrupt context selected registers and accumulators per core for fast interrupt

• Four DAC/Analog comparator modules

• Four DMA channels

• Master core 90 MIPS and slave core 100 MIPS operation

• Operating frequency is 200MHz

• Operation temperature ranges between -40°C and 125°C

• Safety features are DMT, ECC, WDT, CRC, BFRC and fail-safe clock monitoring safety features

• Support for DMX, LIN/J2602 protocols and IrDA

• Three low power modes: Sleep, Idle and Doze

• Two general-purpose 16-bit timers

• Up to 12-channel high-speed PWMs with 250ps resolution

• Zero overhead looping

Applications

• Embedded systems

• LCD monitors and TVs

• Portable hub boxes

• System monitoring and communication functions

수량	한팩당	Per Tube*
47 - 47	₩6,220.92	₩292,392.64
94 - 423	₩6,096.84	₩286,551.48
470 +	₩5,974.64	₩280,817.48
