Texas Instruments Surface Mount Logic Adder, -5.2mA, 6 V, HC, SOIC
- RS 제품 번호:
- 145-7149
- 제조사 부품 번호:
- CD74HC283M96
- 제조업체:
- Texas Instruments
단종
- RS 제품 번호:
- 145-7149
- 제조사 부품 번호:
- CD74HC283M96
- 제조업체:
- Texas Instruments
제정법과 컴플라이언스
제품 세부 사항
74HC Family Complex Function, Texas Instruments
Texas Instruments range of Complex Function products from the 74HC High Speed CMOS Logic Family includes Binary Adders, Magnitude & Identity Comparators, Parity Checkers, 7-segment LCD Latch/Decoder/Drivers and PLL (Phase Locked Loop) ICs. The 74HC Family use silicon gate CMOS technology to achieve operating speeds similar to the LSTTL family but with the low power consumption of standard CMOS integrated circuits.
High-Speed CMOS Logic
Operating Voltage: 2 to 6 V
Compatibility: Input CMOS, Output CMOS
Operating Voltage: 2 to 6 V
Compatibility: Input CMOS, Output CMOS
74HC Family
사양
속성 | 값 |
|---|---|
| Logic Family | HC |
| Logic Function | Binary Full Adder |
| Number of Bits | 4bit |
| Number of Elements per Chip | 1 |
| Maximum High Level Output Current | -5.2mA |
| Maximum Low Level Output Current | 5.2mA |
| Mounting Type | Surface Mount |
| Package Type | SOIC |
| Pin Count | 16 |
| Maximum Propagation Delay Time @ Maximum CL | 210 ns @ 2 V |
| Dimensions | 9.9 x 3.91 x 1.58mm |
| Maximum Operating Supply Voltage | 6 V |
| Minimum Operating Temperature | -55 °C |
| Propagation Delay Test Condition | 50pF |
| Minimum Operating Supply Voltage | 2 V |
| Maximum Operating Temperature | 125 °C |
