Displaytech 164A-BC-BC Alphanumeric LCD Display, Yellow on Green, 4 Rows by 16 Characters, Transflective
- RS 제품 번호:
- 177-5400
- 제조사 부품 번호:
- 164A-BC-BC
- 제조업체:
- Displaytech
본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.
현재 비가용
RS는 이 제품을 더 이상 판매하지 않습니다.
대체품
이 제품은 현재 공급 불가입니다. 아래 제품들은 당사에서 추천드리는 대체품입니다.
개당가격(250개가 1박스안에)
₩35,428.60
- RS 제품 번호:
- 177-5400
- 제조사 부품 번호:
- 164A-BC-BC
- 제조업체:
- Displaytech
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Displaytech | |
| Display Type | Alphanumeric | |
| Character Matrix | 4 Rows by 16 Characters | |
| Characters per Row | 16 | |
| Character Rows | 4 | |
| Character Height | 4.8mm | |
| Character Width | 3mm | |
| Viewing Area Dimensions | 62 x 25mm | |
| Viewing Area Height | 25.2mm | |
| Viewing Area Width | 61.8mm | |
| External Depth | 11mm | |
| Illumination Colour | Yellow | |
| Background Colour | Green | |
| Backlight Type | LED | |
| External Width | 87mm | |
| External Dimensions | 87 x 11 x 60mm | |
| External Height | 60mm | |
| Controller Type | ST7066U | |
| Display Mode | Transflective | |
| Display Matrix Technology | STN | |
| Maximum Operating Temperature | +60°C | |
| Minimum Operating Temperature | -10°C | |
| Operating Temperature Range | -10 → +60°C | |
모두 선택 | ||
|---|---|---|
브랜드 Displaytech | ||
Display Type Alphanumeric | ||
Character Matrix 4 Rows by 16 Characters | ||
Characters per Row 16 | ||
Character Rows 4 | ||
Character Height 4.8mm | ||
Character Width 3mm | ||
Viewing Area Dimensions 62 x 25mm | ||
Viewing Area Height 25.2mm | ||
Viewing Area Width 61.8mm | ||
External Depth 11mm | ||
Illumination Colour Yellow | ||
Background Colour Green | ||
Backlight Type LED | ||
External Width 87mm | ||
External Dimensions 87 x 11 x 60mm | ||
External Height 60mm | ||
Controller Type ST7066U | ||
Display Mode Transflective | ||
Display Matrix Technology STN | ||
Maximum Operating Temperature +60°C | ||
Minimum Operating Temperature -10°C | ||
Operating Temperature Range -10 → +60°C | ||
