- RS 제품 번호:
- 188-2556
- 제조사 부품 번호:
- W29N02GVBIAF
- 제조업체:
- Winbond
일시 품절-다음 입고 날짜는 09/12/2024 (일/월/년) 이며, 그 후 5-10영업일내 홍콩에서 발송. 정확한 입고 수량에 대한 문의는 krenquiry@rs-components.com 로 연락주세요.
추가완료!
단가 개당가격(210개가 1트레이안에)
₩9,923.35
수량 | 한팩당 | Per Tray* |
210 - 210 | ₩9,923.35 | ₩2,083,758.545 |
420 - 630 | ₩9,674.964 | ₩2,031,670.015 |
840 + | ₩9,524.898 | ₩2,000,409.653 |
*다른 단위에 대한 가격 표시 |
- RS 제품 번호:
- 188-2556
- 제조사 부품 번호:
- W29N02GVBIAF
- 제조업체:
- Winbond
제정법과 컴플라이언스
제품 세부 사항
Density : 2Gbit (Single chip solution)
Vcc : 2.7V to 3.6V
Bus width : x8
Operating temperature
Industrial: -40°C to 85°C
Single-Level Cell (SLC) technology.
Organization
Density: 2G-bit/256M-byte
Page size
2,112 bytes (2048 + 64 bytes)
Block size
64 pages (128K + 4K bytes)
Highest Performance
Read performance (Max.)
Random read: 25us
Sequential read cycle: 25ns
Write Erase performance
Page program time: 250us(typ.)
Block erase time: 2ms(typ.)
Endurance 100,000 Erase/Program Cycles(2)
10-years data retention
Command set
Standard NAND command set
Additional command support
Sequential Cache Read
Random Cache Read
Cache Program
Copy Back
Two-plane operation
Contact Winbond for OTP feature
Contact Winbond for block Lock feature
Lowest power consumption
Read: 25mA(typ.3V)
Program/Erase: 25mA(typ.3V)
CMOS standby: 10uA(typ.)
Space Efficient Packaging
48-pin standard TSOP1
63-ball VFBGA
Vcc : 2.7V to 3.6V
Bus width : x8
Operating temperature
Industrial: -40°C to 85°C
Single-Level Cell (SLC) technology.
Organization
Density: 2G-bit/256M-byte
Page size
2,112 bytes (2048 + 64 bytes)
Block size
64 pages (128K + 4K bytes)
Highest Performance
Read performance (Max.)
Random read: 25us
Sequential read cycle: 25ns
Write Erase performance
Page program time: 250us(typ.)
Block erase time: 2ms(typ.)
Endurance 100,000 Erase/Program Cycles(2)
10-years data retention
Command set
Standard NAND command set
Additional command support
Sequential Cache Read
Random Cache Read
Cache Program
Copy Back
Two-plane operation
Contact Winbond for OTP feature
Contact Winbond for block Lock feature
Lowest power consumption
Read: 25mA(typ.3V)
Program/Erase: 25mA(typ.3V)
CMOS standby: 10uA(typ.)
Space Efficient Packaging
48-pin standard TSOP1
63-ball VFBGA
2Gb SLC NAND Flash Memory with uniform 2KB+64B page size.
Bus Width: x8
Random Read: 25us
Page Program Time: 250us(typ.)
Block Erase Time: 2ms(typ.)
Support OTP Memory Area
Random Read: 25us
Page Program Time: 250us(typ.)
Block Erase Time: 2ms(typ.)
Support OTP Memory Area
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
사양
속성 | 값 |
---|---|
Memory Size | 2Gbit |
Interface Type | Parallel |
Package Type | VFBGA |
Pin Count | 63 |
Organisation | 256M x 8 bit |
Mounting Type | Surface Mount |
Cell Type | SLC NAND |
Minimum Operating Supply Voltage | 2.7 V |
Maximum Operating Supply Voltage | 3.6 V |
Block Organisation | Symmetrical |
Length | 11.1mm |
Height | 0.6mm |
Width | 9.1mm |
Dimensions | 11.1 x 9.1 x 0.6mm |
Number of Words | 256M |
Minimum Operating Temperature | -40 °C |
Number of Bits per Word | 8bit |
Series | W29N |
Maximum Operating Temperature | +85 °C |
Maximum Random Access Time | 25µs |
