Hirose Female Crimp Blanking Plug, Wire Size 26AWG, 30 AWG
- RS 제품 번호:
- 184-6165
- 제조사 부품 번호:
- HR12-SC-211
- 제조업체:
- Hirose
본 이미지는 참조용이오니 재확인이 필요하시면 문의해주세요.
대량 구매 할인 기용 가능
Subtotal (1 reel of 10000 units)*
₩2,185,950.00
일시적 품절
- 2026년 7월 03일 부터 배송
더 자세한 내용이 필요하신가요? 필요한 수량을 입력하고 '배송일 확인'을 클릭하면 더 많은 재고 및 배송 세부정보를 확인하실 수 있습니다.
릴당 | 릴당 | 한팩당* |
|---|---|---|
| 1 - 1 | ₩2,185,950.00 | ₩218.40 |
| 2 - 9 | ₩2,131,291.50 | ₩212.55 |
| 10 + | ₩1,918,176.00 | ₩191.10 |
* 참고 가격: 실제 구매가격과 다를 수 있습니다
- RS 제품 번호:
- 184-6165
- 제조사 부품 번호:
- HR12-SC-211
- 제조업체:
- Hirose
사양
참조 문서
제정법과 컴플라이언스
제품 세부 사항
제품 정보를 선택해 유사 제품을 찾기
모두 선택 | 제품 정보 | 값 |
|---|---|---|
| 브랜드 | Hirose | |
| Gender | Female | |
| Product Type | Blanking Plug | |
| Current | 1A | |
| Wire Size | 26, 30AWG | |
| Series | HR12 | |
| For Use With | HR12 Series Connector | |
| Contact Type | Socket | |
| Length | 10mm | |
| Contact Plating | Gold | |
| Voltage | 140V dc | |
| Minimum Operating Temperature | -15°C | |
| Contact Material | Phosphor Bronze | |
| Termination Type | Crimp | |
| Maximum Contact Resistance | 30mΩ | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | No | |
| 모두 선택 | ||
|---|---|---|
브랜드 Hirose | ||
Gender Female | ||
Product Type Blanking Plug | ||
Current 1A | ||
Wire Size 26, 30AWG | ||
Series HR12 | ||
For Use With HR12 Series Connector | ||
Contact Type Socket | ||
Length 10mm | ||
Contact Plating Gold | ||
Voltage 140V dc | ||
Minimum Operating Temperature -15°C | ||
Contact Material Phosphor Bronze | ||
Termination Type Crimp | ||
Maximum Contact Resistance 30mΩ | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- JP
High Performance Miniature Circular Connectors
Snap lock allows for easy insertion and extraction and prevents the accidental un-mating of the connector due to vibration or impact.
The plug diameter range from 12mm dia. to 16mm dia., and satisfies the need for small-size, light-weight and high-density electronic components.
Equipped with internal metal parts and a shielding mechanism, the HR12 (20-contacts) and HR212 feature enhanced protection against EMI.
Snap lock allows for easy insertion and extraction and prevents the accidental un-mating of the connector due to vibration or impact.
The plug diameter range from Ø12mm to Ø16mm, and satisfies the need for small-size, light-weight and high-density electronic components.
Equipped with internal metal parts and a shielding mechanism, the HR12 (20-contacts) and HR212 feature enhanced protection against EMI.
