Block 24V ac 2 Output Through Hole PCB Transformer, 10VA
- RS 제품 번호:
- 347-2650
- 제조사 부품 번호:
- VC 10/2/24
- 제조업체:
- Block
1 <재고있음> 5-9영업일내 홍콩 발송
추가완료!
단가 개당
₩22,309.857
| 수량 | 한팩당 |
| 1 - 8 | ₩22,309.857 |
| 9 - 17 | ₩21,819.985 |
| 18 + | ₩21,350.812 |
- RS 제품 번호:
- 347-2650
- 제조사 부품 번호:
- VC 10/2/24
- 제조업체:
- Block
제정법과 컴플라이언스
- COO (Country of Origin):
- DE
제품 세부 사항
PCB Mount 230Vac Primary VC/VCM Series
Single and twin secondary windings for series or parallel connection
Vacuum resin moulded to UL94-V0 rating
Low inter-winding capacitance
Low radiated noise
100% electrical and flash tested
Extra fixing points for secure board mounting (25 VA and 36 VA)
Vacuum resin moulded to UL94-V0 rating
Low inter-winding capacitance
Low radiated noise
100% electrical and flash tested
Extra fixing points for secure board mounting (25 VA and 36 VA)
Note
To conform to VDE 0550,UL506 all transformers with 2 x 24V outputs should not have their secondaries connected in series.
Standards
EN 61 558 IEC 61558
Approvals
ENEC, UL recognised
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
사양
속성 | 값 |
|---|---|
| Secondary Voltage Rating | 24V ac |
| Power Rating | 10VA |
| Primary Voltage Rating | 230V ac |
| Number of Outputs | 2 |
| Length | 51mm |
| Width | 34.6mm |
| Depth | 43mm |
| Dimensions | 51 x 34.6 x 43mm |
| Weight | 280g |
| Mounting Type | Through Hole |
| Maximum Temperature | +40°C |
